Setup ZFS Raid on Ubuntu Server

This guide is designed to give you the quickest way to get a "net new" RAID setup on Ubuntu with a minimum of 3 or more (ideally) matching drives.

At my house, I run a small media server for the local network. From backups of my various devices to running small test projects or archiving my retro game ROM collections, we use a LOT of storage. The server in reference is a purpose-built computer with a smattering of various sized WD Red's. We will be adding NEW drives to the computer to build the POOL/RAID.

Step 1 - Install Drives

In my case, I had 4 fresh 12TB WD Red's, so I shut down the box, popped the case and installed the new drives. I took special effort to make sure that the new drives were clustered at the end of the SATA controller. My motherboard has 2 M.2 slots and 6 SATA ports. Boot is an M.2 and I had 3 other SATA (0 index) drives, so the new ones were SATA 3, 4, & 5.

Once the drives are installed, power the box back on, log in and use the lsblk command to display the drives and their assigned drive letter.

❯ lsblk
NAME                      MAJ:MIN RM   SIZE RO TYPE MOUNTPOINTS
sda                         8:0    0   3.6T  0 disk
└─sda1                      8:1    0   3.6T  0 part /media/disk1
sdb                         8:16   0   3.6T  0 disk
└─sdb1                      8:17   0   3.6T  0 part /media/disk2
sdc                         8:32   0  10.9T  0 disk
sdd                         8:48   0  10.9T  0 disk
sde                         8:64   0  10.9T  0 disk
sdf                         8:80   0  10.9T  0 disk
nvme0n1                   259:0    0 476.9G  0 disk
├─nvme0n1p1               259:1    0     1G  0 part /boot/efi
├─nvme0n1p2               259:2    0     2G  0 part /boot
└─nvme0n1p3               259:3    0 473.9G  0 part
  └─ubuntu--vg-ubuntu--lv 252:0    0   100G  0 lvm  /

Notice the 3 matching entries under sdd, sde, sdf. Don't do anything else to the drives - no partitioning, no formatting, nothing... Just crack the package and pop it in.

Step 2 - Create the ZFS Pool

Now the fun begins. We are now going to create a ZFS pool that in the example is names MediaPool, but you can change that to whatever you like.

❯ sudo zpool create -f MediaPool raidz1 /dev/sdd /dev/sde /dev/sdf

And then check the status to make sure everything looks right.

❯ sudo zpool status
  pool: MediaPool
 state: ONLINE
config:

	NAME        STATE     READ WRITE CKSUM
	MediaPool   ONLINE       0     0     0
	  raidz1-0  ONLINE       0     0     0
	    sdd     ONLINE       0     0     0
	    sde     ONLINE       0     0     0
	    sdf     ONLINE       0     0     0

errors: No known data errors

The zpool create command will also mount your MediaPool to the /MediaPool address taken from the name of the pool itself.

❯ df -h
Filesystem                         Size  Used Avail Use% Mounted on
...
MediaPool                           32T  0T     32T   0% /MediaPool

Step 3 - Enable ZFS Compression

LZ4 is the default compression algorithm for ZFS because it delivers a great balance of speed, efficiency, and storage savings with negligible overhead. This makes it a solid choice for ZFS RAID pools, particularly in environments where performance and responsiveness are key concerns.

❯ sudo zfs get compression MediaPool
NAME  PROPERTY     VALUE           SOURCE
MediaPool  compression  on         default
❯ sudo zfs set compression=on MediaPool
❯ sudo zfs get compression MediaPool
NAME       PROPERTY     VALUE           SOURCE
MediaPool  compression  on              local

Step 4 - Increase Block Size

Since I generally work with large files that do extended, sequential reads and writes, so adjusting the block size to 1M is suggested.

❯ sudo zfs get recordsize MediaPool
NAME       PROPERTY    VALUE    SOURCE
MediaPool  recordsize  128K     default
❯ sudo zfs set recordsize=1M MediaPool
❯ sudo zfs get recordsize MediaPool
NAME       PROPERTY    VALUE    SOURCE
MediaPool  recordsize  1M       local

Intermission - Start Loading Data

Now that we have a striped pool, it's time to start putting some files on it. I am starting with about 8TB of files, so this is an overnight operation.

Write Caching and SLOG

Write caching is also know as L2ARC on ZFS. L2ARC is a secondary read cache in ZFS that extends the primary ARC (Adaptive Replacement Cache), which resides in RAM, by using a fast storage device such as an SSD or NVMe drive.

In ZFS, the SLOG (Separate Intent Log) is an optional dedicated device used to store the ZFS Intent Log (ZIL). The ZIL temporarily holds synchronous write operations before they are committed to the main storage pool.

For both of these cases, I used a 500GB NVME drive split evenly for that purpose. Here's how I set it up.

  1. Install the hardware, boot the machine and identify the device ID, such as /dev/nvme1n1 .
  2. Use parted to split the disk in half:
❯ parted /dev/nvme1n1

(parted) mklabel gpt
(parted) mkpart primary 0% 50%
(parted) mkpart primary 50% 100%
(parted) quit
💡
Throw a (parted) print in between those commands to verify that things are going as planned if you need.

After that, you should be left with nvme1n1p1 and nvme1n1p2 or similar.

  1. Assign those partitions to their respective operations:
❯ sudo zpool add -f MediaPool cache nvme1n1p1
❯ sudo zpool add -f MediaPool log nvme1n1p2

Assuming those didn't throw errors, you can verify that these new functions are active by running the following command:

❯ sudo zpool status

You should see an output similar to below:

  pool: MediaPool
 state: ONLINE
config:

	NAME         STATE     READ WRITE CKSUM
	MediaPool    ONLINE       0     0     0
	  raidz1-0   ONLINE       0     0     0
	    sdb      ONLINE       0     0     0
	    sdc      ONLINE       0     0     0
	    sdd      ONLINE       0     0     0
	    sde      ONLINE       0     0     0
	logs
	  nvme1n1p2  ONLINE       0     0     0
	cache
	  nvme1n1p1  ONLINE       0     0     0

errors: No known data errors

And with that, you have a L2ARC caching and SLOG.

Monitoring and Alerting

Now that you have this fancy ZFS Raid and storage pool, you probably need to know when something goes wrong, and knowing about it quickly can mean the difference between being able to recover everything easily or losing the data that you have stored.

I have done this with a simple Python script I wrote that is attached to a CRON and ran periodically. I am generally a regular on Discord, and I use Email for ongoing reporting, so my scripts use both mechanisms to get your attention. Click the link below to get started:

GitHub - cmivxx/zpool-monitor: Python script to monitor Zpool status.
Python script to monitor Zpool status. Contribute to cmivxx/zpool-monitor development by creating an account on GitHub.

Scrubbing the Pool

Zpool scrubbing is a maintenance process in ZFS that scans all data in a storage pool to verify its integrity. It checks each block against its checksum to detect any silent data corruption. If an error is found and the pool has redundancy (like mirrors or RAID-Z), ZFS will automatically repair the corrupted data. Regular scrubbing helps ensure the health and reliability of stored data over time.

I have my scrubbing set to run on the 1st of every month. The contab config below represents that.

Start by opening your crontab for editing.

❯ sudo crontab -e

The add the following lines at the bottom:

# Add the following line
0 0 1 * * /sbin/zpool scrub MediaPool
💡
For more information on crontab's and for help changing the frequency, please visit: The Crontab Guru

Coming Soon

  • Snapshot Information

Bonus Tips

💡
You can move drives between computers or between re-installs of the application (preserve drive order) After moved, just type zpool import and follow the on screen instructions.
